Kubota WSM L3560 User Manual

ELECTRICAL SYSTEM
L3560, L4060, L4760, L5060, L5460, L6060, WSM
9-S19
9Y1210824ELS0012US0
HST
1
Battery Voltage More than 12 (V)
Coolant temperature sensor voltage
−30 → 20 → 100 °C
(−22 → 68 → 212 °F)
4.73 → 3.13 → 0.89 (V)
Fuel sensor voltage F to E 0.31 to 3.24 (V)
2
Engine revolution Idling to Max. 800 to Max. (n/min.)
Throttle sensor 1 voltage Idling → Max. 0.43 to 1.43 → 3.57 to 4.57 (V)
Throttle sensor 2 voltage Idling → Max. 3.57 to 4.57 → 0.43 to 1.43 (V)
HST range gear shift lever sensor
voltage
L → N → M → N → H
0.49 to 1.49 → 1.09 to 2.09 → 1.98 to
2.98 → 2.88 to 3.88 → 3.49 to 4.49 (V)
3
HST Pedal sensor 1 voltage (main) Reverse → N → Forward
0.61 to 1.61 → 2.0 to 3.0 → 3.39 to 4.39
(V)
HST Pedal sensor 2 voltage (sub) Reverse → N → Forward
3.39 to 4.39 → 2.0 to 3.0 → 0.61 to 1.61
(V)
Swashplate position sensor 1 voltage
(main)
Reverse → N → Forward
0.61 to 1.61 → 2.0 to 3.0 → 3.39 to 4.39
(V)
Swashplate position sensor 2 voltage
(sub)
Reverse → N → Forward
3.39 to 4.39 → 2.0 to 3.0
→ 0.61 to 1
.61
(V)
4
HST forward solenoid N → Forward 0 to 1.6 (A)
HST Reverse solenoid N → Reverse 0 to 1.6 (A)
PTO revolution Idling → Max. PTO Revolution (n/min)
5
DOC Inlet TEMP. (Intake 1 Temp)
200 → 650 °C
(140 → 1202 °F)
3.94 → 0.66 (V)
DPF Inlet TEMP (Intake 2 Temp)
200 → 650 °C
(140 → 1202 °F)
3.94 → 0.66 (V)
DPF Outlet TEMP (Outlet Temp)
200 → 650 °C
(140 → 1202 °F)
3.94 → 0.66 (V)
Transmission
Model
Display Contents Condition Value (unit)
KiSC issued 03, 2016 A

Kubota WSM L3560 Specifications

General

Type	Compact Utility Tractor
Engine Model	Kubota V1505-T
Horsepower	37 hp (27.6 kW)
Fuel Type	Diesel
Drive	4WD
Hydraulic System	Open center
3-Point Hitch	Category I
PTO Horsepower	30.5 hp (22.7 kW)
Transmission	Hydrostatic
Number of Gears	3-range
Height	91.3 in (232 cm)
Tire Size (Front)	7-16
Tire Size (Rear)	15-19.5
Displacement	91.4 cu. in. (1, 499 cc)
