10 Parameter reference
10.2 Parameter list | C00036
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00036
C00039
C00050
C00051
Parameter | Name:
C00036 | DCB: Current
Data type: INTEGER_16
Index: 24539
d
= 5FDB
h
Current value in [%] for DC-injection braking
•100% ≡ Imax in motor mode (C00022
)
DC injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 150.0 50.0 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00039 | Fixed setpoint x (L_NSet_1 n-Fix)
Data type: INTEGER_16
Index: 24536
d
= 5FD8
h
FB L_NSet_1: Fixed speed setpoints (JOG values) for the setpoint generator
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00039/1 40.0 % Fixed setpoint 1
C00039/2 60.0 % Fixed setpoint 2
C00039/3 80.0 % Fixed setpoint 3
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00050 | MCTRL: Speed setpoint
Data type: INTEGER_32
Index: 24525
d
= 5FCD
h
Display of the speed setpoint at the speed setpoint input of the motor control
Display range (min. value | unit | max. value)
-9999 rpm 9999
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00051 | MCTRL: Actual speed value
Data type: INTEGER_32
Index: 24524
d
= 5FCC
h
Display of the actual speed value of the motor shaft
Note:
The displayed value only corresponds to the real actual speed value of the motor shaft if an encoder is connected to
the motor and the evaluation of the feedback signal has been set correctly ("Closed loop" operation).
In case of operation without speed feedback, the signal is calculated from the motor control and thus may not cor-
respond to the real actual speed.
Display range (min. value | unit | max. value)
-9999 rpm 9999
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
