10 Parameter reference
10.2 Parameter list | C00029
243
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00029
C00033
C00034
Parameter | Name:
C00029 | AINx: Input current
Data type: INTEGER_16
Index: 24546
d
= 5FE2
h
Display of the input current at the analog input
• When the analog input has been configured for current measurement (C00034/1
=1 or 2).
•When C00034/1
is set = 2 (4 ... 20 mA), 0 ... 16 mA is displayed.
Analog terminals
Display range (min. value | unit | max. value)
0.0 mA 20.0
Subcodes Info
C00029/1 AIN1: Input current
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00033 | AINx: Output value
Data type: INTEGER_16
Index: 24542
d
= 5FDE
h
Display of the output value in percent of the analog input amplifier
• 100 % ≡ 16384 ≡ +10 V / +20 mA
Analog terminals
Display range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Info
C00033/1 AIN1: Output value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00034 | AINx: Configuration
Data type: UNSIGNED_8
Index: 24541
d
= 5FDD
h
Configuration of the analog input for current or voltage measurement
Analog terminals
Selection list Info
0 0...+10 V Input signal is voltage signal 0 V ... +10 V
• 0 V ... +10 V ≡ 0 % ... +100 %
1 0...+5V With external load resistor (250 Ohms):
Input signal is the current signal 0 mA ... 20 mA
•0mA...20mA ≡ 0%...+100%
2 1...+5V (4...20mA) With external load resistor (250 Ohms):
Input signal is the current signal 4 mA ... 20 mA
•4mA...20mA ≡ 0%...+100%
• The current loop is monitored for open circuit
(I < 4 mA) by the device.
Subcodes Lenze setting Info
C00034/1 0: 0...+10 V AIN1: Config.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
