5 -11
Low Good Exceed
② Standard air pressure - See chapter 4-4-(6), “Tires and Load capacity” in this manual.
▶ It is not allowed to remove/attach or change the tire arbitrarily.
Carry out the work in the tire repair center equipped with a expert and special
safety tools.
▶ When checking tire pressures, keep the body away from the valve mechanism or
cap.
▶ The tire pressures vary depending on the load weighing on the axles.
Caution
(8) Tire air pressure and damage
① Check
Check the air pressure or the damage of the tires
daily. Always use the correct pressure for each
axle, and if the tire is damaged, change it with a
new one.
Ensure tire pressures are not lower than the
correct values, to prevent ;
-blown tires;
- bead wear;
- internal damage;
- irregular wear and short service life.
Do not over-inflate the tires, as this may lead to damage in the event of impact and, in extreme
conditions, the tire rim may be deformed or the tire may burst.
▶ If there are lots of foreign materials such as dry grass stuck to the radiator screen,
the cooling efficiency will be reduced and the engine can be overheated.
▶ Clean the radiator only while the engine is stopped.
▶ If cleaning with water, have to take care not to spray water to the Tier-4 engine
enhanced with electric and electronic parts. If possible, DO NOT USE WATER.
Caution
(7) Cleaning of Radiator and
Radiator screen
Remove dust or dry grass stuck to the radiator or
radiator screen on a daily basis.
To easy access, unscrew the knob on the right-
hand side cover of the radiator and pull the
radiator screen to the outside.
When cleaning the radiator with compressed air,
let the air flow from engine side to the fan side.
Radiator screen
