LS tractor XR4140 User Manual

5 -34
5-9. Every 300 hour check
(1) Replacing Engine oil and Filter
▶ When engine oil is warm, the
impurities can be drained
completely.
Notice
① Drain Engine oil
 Run the engine for a few minutes to warm oil.
 Park the tractor on a level surface.
 Remove both LH and RH drain plugs of oil pan
and drain the oil completely.
③ Fill Engine oil
 Tighten the drain plugs. (Tightening torque :
40±5 N.m) (29.5±5 lbs-ft)
 Add new engine oil and check the oil level is
between MIN and MAX mark on the gauge.
 For oil specification, see chapter 5-3, “Lubricants
and Capacity” or the last page in this manual.
 Check any leakage of the engine while running
the engine for several minutes at idle rpm.
 Stop the engine. After about 5~10 minutes later,
check again if the oil level is between MIN and
MAX marks. Install the oil gauge.
② Replace Engine oil filter
 Clean carefully around the filter.
 Coat clean engine oil on the packing of new filter
and check the packing is placed well in the
groove.
 Turn the oil filter counter-clockwise to remove it
with a filter wrench.
 Turn the new filter clockwise to assemble it until
the packing makes contact with the mounting
surface. Tighten ¾ to 1 turn more after packing
contact.
 If the metal is attached to the element of oil filter
to be disassembled, contact your authorized
dealer.
Close
Open
Packing
Engine oil gauge
Oil filling inlet
Drain plug (both side)
Engine oil filter
Oil filling inlet
