LS tractor XR4140 User Manual

2 -4
warning
▶Do not arbitrarily remove the seat switch. When replacing the seat, make sure to
check if the seat switch is correctly in place. If not, the engine can not be started.
Seat switch
(2) Driver’s seat (HST type)
 At the lower end of the seat, there is a switch to
detect that operator is sitting in seat.
 If the operator gets up from the seat while
engine is running, the engine will stop
automatically for safety in case of ;
① getting up from the seat for more than 2
seconds with HST pedal NOT in neutral position.
② the HST pedal is in NEUTRAL and rear PTO is
engaged without applying the parking brake.
③ the Middle PTO lever (optional) is engaged.
 Before leaving the driver’s seat, turn the PTO
switch to “OFF” and place the Middle PTO lever
(if fitted) on “OFF” position, and apply the parking
brake.
Seat switch
ROLL-BAR
CABIN

LS tractor XR4140 Specifications

General

Brand	LS tractor
Model	XR4140
Category	Tractor
Language	English
