Published 4-20-2015, Control # 502-01 9-1
RT540E SERVICE MANUAL LUBRICATION
SECTION 9
LUBRICATION
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Environmental Protection . . . . . . . . . . . . . . . . . . . 9-1
Lubrication Intervals . . . . . . . . . . . . . . . . . . . . . . . 9-1
Arctic Conditions Below -18°C (0°F). . . . . . . . . . . 9-1
Arctic Conditions Down To -40°F.. . . . . . . . . . . . . 9-2
Surface Protection for Cylinder Rods . . . . . . . . . . 9-2
Wire Rope Lubrication . . . . . . . . . . . . . . . . . . . . . . 9-3
Lubrication Points . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
CraneLUBE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Steering and Suspension . . . . . . . . . . . . . . . . . . . 9-5
Axles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Drive Train . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-9
Drive Train (continued) . . . . . . . . . . . . . . . . . . . . 9-11
Outriggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13
Turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-15
Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Boom (continued) . . . . . . . . . . . . . . . . . . . . . . . . 9-19
Hoist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Hydraulic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23
Carwell® Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 9-25
Protecting Cranes From Rusting . . . . . . . . . . . . . 9-25
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 9-25
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 9-26
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-26
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 9-26
GENERAL
Following the designated lubrication procedures is important
in ensuring maximum crane lifetime and utilization. The
procedures and lubrication charts in this section include
information on the types of lubricants used, the location of
the lubrication points, the frequency of lubrication, and other
information.
ENVIRONMENTAL PROTECTION
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
Potentially harmful waste used in Manitowoc cranes includes
— but is not limited to — oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
• Immediately clean up any spills.
LUBRICATION INTERVALS
The service intervals specified are for normal operation
where moderate temperature, humidity, and atmospheric
conditions prevail. In areas of extreme conditions, the
service periods and lubrication specifications should be
altered to meet existing conditions. For information on
extreme condition lubrication, contact your local Grove
Distributor or Manitowoc Crane Care.
Arctic Conditions Below -18°C (0°F).
In general, petroleum based fluids developed especially for
low temperature service may be used with satisfactory
results. However, certain fluids, such as halogenated
CAUTION
Chassis grease lubricants must not be applied with air
pressure devices as this lubricant is used on sealed
fittings.
CAUTION
The multipurpose grease installed during manufacture is
of a lithium base. Use of a noncompatible grease could
result in damage to equipment.
Reference Only
