54 TRAX ZP-AJ01E AJ0383DE
9 SPECIFICATIONS
9
Specifications
Specifications TRAX
Specifications are valid at nominal input voltage and an ambient
temperature of +25°C ±5°, (77°F). Specifications are subject to
change without notice.
Evironment
Application
field
For use in high-voltage substations and industrial
environments
Temperature
Operating -20°C to +55°C (-4°F to +131°F)
Storage -20°C to +70°C (-4°F to +158°F)
Humidity < 90%RH, non-condensing
CE- marking
EMC 2004/108/EC
LVD 2006/95/EC
General
Mains input 100-240 V, 50/60 Hz (± 10%)
Input current ≤ 16 A continuous
Short-term up to 30 A < 60 s
Main fuses F1 and F2, 25 A
TEST GROUND
To be connected to the test object ground before
connecting any other cables to the unit.
GROUND
For connecting an additional ground between
the main unit and accessories or to ground exter-
nal objects e.g. optional trolley
Dimensions 475 x 315 x 330 mm (excl. handles)
(18.7” x 12.4” x 13”)
Weight
TRA X 219 25 kg (55 lbs)
TRAX 220 26 kg (57 lbs)
TRAX 280 30 kg (66 lbs)
Display
Size 10.4”
Resolution 1024x768 XGA
Type TFT touch
Contrast ratio 1000:1
Brightness 1000 cd/m
2
Outputs
Item Specification Comment
0-2200 V
AC
1 A, 1 min
0.2 A, >2 h
Frequency range:
5-70 Hz
The output is disconnected
with a relay and the output
is “live” only when this
generator is selected
0-250 V
AC
/
0-10 A
AC
10 A, 1 min
20 A, max 10 s
2.5 A, >2 h
Frequency range:
5-505 Hz
0-200 A
AC
200 A/6 V, 1 min
80 A, >2 h
Frequency range:
45-70 Hz
TRAX220
0-800 A
AC
0-800 A/6 V, 1 min
0-200 A/10 V, >2 h
Frequency range:
45-70 Hz
TRAX280
0-16 A
DC
16 A, continuous
1 A continuous
0-300 V
DC
10 A,1 minute
2.5 A, >2 h
Rectified DC. Intended to
be used as e.g. auxiliary DC
supply
0-100 A
DC
100 A, 2 minutes
70 A, continuous
DC output
power
Max 1000 VA ,
continuous
Max 50 V compli-
ance voltage
Binary output 250 V / 35 A (max)
2 x 0-10000 s
Output contacts for OLTC
and circuit breaker opera-
tion with internal voltage
and current measurements
AUX
CONTROL 54 V DC Ethernet communication
and power to accessories.
POWER 0-235 V AC Directly from power ampli-
fier for powering accesso-
ries (TDX / TCX)
With
TRAX TDX
12 kV AC
0-12 kV, 1 min
0-12 kV / 300 mA,
4 min
0-12 kV / 100 mA,
continuous
With
TRAX TCX
2000 A AC
0-2000 A/2.4 V,
1 min
0-1000 A/4.8 V,
1 min
