4 Operation
912/913/914 Meter
￭￭￭￭￭￭￭￭
25
4.3 Status displays
The main dialog displays contain corresponding graphical elements to
show instrument and sensor statuses.
4.3.1 Rechargeable battery status
The battery status is displayed in 6 stages with colored graphical elements.
The battery is fully charged and charging is complete.
The battery is nearly full but still charging.
The battery is charged to 75%.
The battery is charged to 50%.
The battery is charged to 25%.
The battery is empty.
NOTICE
Flash icon
The flash icon indicates that the instrument is connected to a power
source for charging.
4.3.2 User rights
The user rights can be set in the Menu under User as Dialog type:
1. Expert
Use of the instrument is unrestricted. All functions are available.
2. Routine
The Configuration and Sensors menu structures are locked.
If the key icon
(on top in the main dialog) is displayed, then the user
menu is limited to the functions for Routine users.
4.3.3 Sensor quality for pH electrodes
The sensor quality is indicated with 3 colored graphical elements.
The criteria for the display status are set in the calibration parameters (see
chapter 4.7.5, page 48).
