4.5 Basic operation
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
30
￭￭￭￭￭￭￭￭
912/913/914 Meter
4.5.2 Main dialog with one measuring channel
The corresponding measuring channel is displayed according to the selec-
tion.
In addition, the display and input fields ID1, ID2 and User are displayed in
the main dialog with one measuring channel.
Figure 15 Operation - Main dialog, one-channel pH
1
Battery state of charge
(see chapter 4.3.1, page 25).
2
Menu access
(see "Accessing the menu structures", page
31).
3
Sensor condition
(see chapter 4.3.3, page 25).
(see chapter 4.3.4, page 26).
4
Measuring channel display
5
Calibration interval display
Time in days until the next calibration is due.
6
Print/save measured value
Button for the functions print, save or
print+save.
The measured value with the currently
selected measuring channel is printed and/or
saved.
7
ID1
Input option for sample designation/identifi-
cation (e.g. name, number, etc.).
8
ID2
Input option for sample designation/identifi-
cation (e.g. batch number, lot number, etc.).
9
Users
Input option for the user name or display of
the preset value from the User menu dialog
(see chapter 4.7.8, page 57).
10
Date/time display
