Metrohm 912 User Manual

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 Operation
912/913/914 Meter
￭￭￭￭￭￭￭￭
29
Figure 14 Operation - Main dialog, two-channel pH and conductivity
1
Battery state of charge
(see chapter 4.3.1, page 25).
2
Menu access
(see "Accessing the menu structures", page
31).
3
Sensor condition
(see chapter 4.3.3, page 25).
(see chapter 4.3.4, page 26).
4
Display measuring channel 1
5
Calibration interval display
Time in days until the next calibration is due.
6
Display measuring channel 2
7
Print/save measured value
Button for the functions print, save or
print+save.
Both measured values are printed and/or
saved.
8
Date/time display
NOTICE
The procedure for functions of the main dialog with two measuring
channels is the same as for the main dialog with one measuring chan-
nel:
￭ (see "Accessing the menu structures", page 31).
￭ (see "Toggling from one-channel to two-channel view", page 31).
