Miele MasterChef H 4682 B User Manual

Technical Information
51
MasterChef Ovens
Figure 5-28: Self-Clean Thermostat Removal
5.28 Self-Clean Thermostat Resistance Values
Temperature (°F (°C)) Resistance
32 (0) 1000Ω
68 (20) 1078Ω
77 (25) 1097Ω
86 (30) 1117Ω
122 (50) 1194Ω
212 (100) 1385Ω
302 (150) 1573Ω
392 (200) 1758Ω
482 (250) 1941Ω
572 (300) 2120Ω
Table 5-1: Self-Clean Thermostat Resistance Values
5.29 Rotisserie Motor (M15) Removal
1. Remove the door(s) (Section 5.2).
2. Remove the oven for service (Section 5.5).
3. Remove the rear panel(s) (Sections 5.11 and 5.12).
4. Remove the screws securing each motor (see Figure 5-29, Item 1).
5. Disconnect all connections to the motor(s).
6. Remove the motor(s).

Miele MasterChef H 4682 B Specifications

General

Brand	Miele
Model	MasterChef H 4682 B
Category	Oven
Language	English
