Technical Information
56
MasterChef Ovens
4. Remove the spacer brackets (Figure 5-37, Item 2).
5. Remove the inner glass pane (Figure 5-37, Item 1).
Figure 5-37: Door Inner Glass Pane Removal (H 39x, H 478x, H 488x)
Note:
To prevent cooking vapors from entering the door assembly, ensure that the
seal remains seated when installing the inner glass pane into the door frame
assembly.
5.35 Door Hinge Removal
5.35.1 H 39x, H 488x, H 489x
1. Remove the door (Section 5.2.1).
2. Remove the door outer glass pane (Section 5.32).
3. Remove the screws securing the hinge (Figure 5-38, Item1)
4. Remove the hinge from the door frame.
5. Repeat for the other side.
