Technical Information
8
MasterChef Ovens
1.2 Appliance Overview
1.2.1 Single Oven (Typical)
Figure 1-1: Overview of Single Oven
1
Control panel
2
Child safety lock
3
Door contact switch
4
Upper heating element
5
Catalytic liner
6
Convection fan
7
Light
8
Six non-tip level runners
9
Oven door
