2-1-2. Group icons
Each group icon indicates the operation condition of the group.
Unit ON/OFF Error
Interlocked LOSSNAY
ON/OFF
Unit unknown
Air conditioning unit
group
LOSSNAY unit
(ventilator) group
General equipment
group
Air To Water (PWFY)
unit group
Note: Icons can be changed in the group settings screen in the initial settings. Refer to the Instruction Book (Initial Settings) for settings
methods.
2-1-3. Operation mode
The operation mode of each group currently in use is displayed.
Unit Cool Dry Fan Heat Auto Auto Setback
Air conditioning
unit group
Cool
Heat
Unit Bypass Heat Recovery Auto
LOSSNAY unit
(ventilator) group
Unit Heating Heating ECO Hot Water Anti-freeze Cooling
Air To Water
(PWFY) unit group
For general users Chapter 4
