94
WT07996X02
2-6-4. CSV Output
Operation data, such as apportioning parameters, metering device data, and energy management data, can be
output in a CSV format from the CSV Output screen.
Important
● File names, as well as date formats, delimiter characters, decimal separators, temperature units (°C, °F), MCP (PI controller)
measurement units, and MCT (AI controller) measurement units (temperature, humidity) within the files output as CSV will
use formats set as initial settings. Refer to the Instruction Book (Initial Settings) for settings methods.
● Operation data can be output for each centralized controller. Outputting operation data for all centralized controllers at once
is not possible.
● Output from tablet is not possible.
Note: Use Microsoft
®
Excel
®
2007 or later to read a CSV file.
(1) Click [CSV Output] to download a tool “CSV File Download Tool” for carrying out CSV output from
AE-200/AE-50/EW-50.
Note: Depending on the browser, a warning message may appear when downloading the tool for the first time. The following
is a download method when Google Chrome is used.
1. Click [CSV Output] to display the screen below. Click [Advanced].
2. Click [Proceed to “IP address of the centralized controller” (unsafe)].
3. A warning message will appear in the taskbar of the browser. Click [Keep] to download the tool.
(2) Execute the saved “AEcsvdl.jar” to start up the CSV File Download Tool.
Note: If the “AEcsvdl.jar” file is associated with other applications, the CSV File Download Tool will not start up. Remove the
association.
Note: If [Keep] is clicked, the “AEcsvdl.jar” file will be saved in the specified folder. In this case, double clicking the file will also
start the CSV File Download Tool.
CSV File Download Tool
Advanced Proceed to “IP address of the
centralized controller” (unsafe)
Connection destination
(IP address or Host name)
Save destination
Charge Parameters
Energy management data
Delete history
Browse...
Metering device data
Close
To Next Page
