36
WT07996X02
2-1-4. Selecting the icons of the groups to be operated
In the screens under the [Monitor/Operation] menu, select the icon(s) of the group(s) to be operated as explained
below.
[1] Selecting group icons
(1) Selecting unit group(s)
(1) In the Floor Layout screen or group list, click the icon(s) of the group(s) you want to operate.
The selected group icon(s) will appear with a checkmark and a dark blue frame.
Click again to deselect.
To cancel all group selections, click [Deselect all] or [Close] in the taskbar.
(2) Selecting all unit groups on the selected floor
(1) Select the floor for which you wish to perform operation by making a selection in “Displayed floor switching
area” and then “Floor display area” on the Home (Preview) screen, and then click [Select all] on the [Floor
Layout] screen.
All icon(s) on the selected floor will appear with a checkmark and a dark blue frame.
To cancel all group selections, click [Deselect all] or [Close] in the taskbar.
Floor Layout
Deselect
all
Group
selection
Close
Group
selection
Deselect all
Close
Group list
Home (Preview)
Deselect
all
①Displayed floor
switching area
Select the unit of floors
that includes the floor for
which you wish to perform
operation.
Close
Floor Layout
② Floor display area
Select the floor for which
you wish to perform
operation.
Select all
To Next Page
