Mitsubishi alpha 2 User Manual

α 2 Simple Application Controllers
Introduction 1
ENG-6
1.4 System Configuration
Figure 1.3: System Configuration(AL2-10MR-*)
Figure 1.4: System Configuration(AL2-14MR-*,AL2-24MR-*)
*1 Further information can be found in chapter 8.
Table 1.5: System Configuration
Item Using Cable
1 AL-232CAB
2 AL2-GSM-CAB
3
RS-232C cross cable
*1
4
RS-232C straight cable for the modem
*1
5 RS-232C straight cable for the modem (specified by Modem manufacturer)
α 2
Series

Personal computer
- Programming Software
(AL-PCS/WIN-E)
Standard Connection to the Programming Softoware
α 2
Series
GSM
Modem
Remote Maintenance (via Telephone Line)
Remote Maintenance, e-Mail (via GSM)






Personal computer
- Programming Software
(AL-PCS/WIN-E)
- Dedicated protocol
- e-Mail application
Cellular Phone
(Supporting SMS message)
Normal Modem Normal Modem
Normal Modem
Sending SMS Message
Using Dedicated Protocol
Standard Connection to the Programming Softoware
