Mitsubishi alpha 2 User Manual

α 2 Simple Application Controllers
AL2-2PT-ADP 12
ENG-62
12.3 Specification
Table 12.3: General Specification
Item Content
Operating Temperature (-25) - 55°C / (-13) - 131°F
Storage Temperature (-30) - 70°C / (-22) - 158°F
Humidity 35 - 85% Relative humidity, no condensation
Vibration Resistance - DIN Rail mounting
Conforms to IEC 68-2-6; 10-57: Hz: 0.075mm
Constant Amplitude
57-150Hz:9.8m/s
2
Acceleration. Sweep Count for
X, Y, and Z: 10 times (80 minutes in each direction)
Shock Resistance
Conforms to IEC 68-2-27: 147m/s
2
Acceleration, Action
Time: 11ms 3 times in each direction X, Y and Z
Noise Immunity 1000 Vpp, 1μs, 30-100Hz tested by a noise simulator
Dielectric Withstand Voltage
500V AC~>1min per IEC60730-1 between all terminals
and the DIN43880 control box or equivalent.
Insulation Resistance
7MΩ 500V DC IEC60730-1 between all terminals and
the DIN43880 distribution box or equivalent
Operation Ambience To be free of corrosive gases
Table 12.4: Power Specification
Item Content
External Supply for Analog output 24V DC +20%, -15%
Power consumption 1.0W
Table 12.5: Adjustment Standard
Item Content
EC Directive EMC Directive
EN61000-6-1
EN61000-6-2
EN61000-6-3
IEC IEC60730-1
UL, CUL UL508
Table 12.6: Hardware Specifications
Item
Specification
Centigrade (°C) Fahrenheit (°F)
Input
Specification
Plantinum temperature PT100 sensors (100Ω), 3-wire,
Temperature coefficient: JIS C 1604-1997 (IEC 751)
Compensated
Range
-50°C - 200°C-58°F - 392°F
Overall accuracy
±1.5% (range of all temperatures) and
±1.0% (at 25°C)
±1.5% (range of all temperatures) and
±1.0% (at 77°F)
Resolution 0.5°C / digit
D/A Conversion
Time
20.5ms
Isolation Circuit No isolation between channels (input/output) and power
