Mitsubishi alpha 2 User Manual

α 2 Simple Application Controllers
DCF77 Radio Clock 10
ENG-51
ENG
10.4.2 DCF77 Setup from α2 display
1) From the TopMenu, scroll to “ClockSet” and press the “OK” key. From the options that
appear, scroll to “Radioclock” and press the “OK” key. Only one option appears if the
Radioclock has not been activated. Scroll to “Radioclock” and press the “OK” key.
2) From the options that appear, scroll to “DCF77” and press the “OK” key.
3) Choose the
α2 Analog Input (I01-I08) that carries the DCF77 antenna signal. More options
will appear under the Radioclock menu. Scroll to “ Input” and press the “OK” key.
*1
4) Enter the Analog Input (I01-I08) with the +, - buttons and press the “OK” key.
5) Adjust for the timezone difference between Frankfurt Germany and the controllers’ location.
This amount is added to the received time. Scroll to “TimeDiffer” and press the “OK” key.
6) Select the timezone difference in half hour increments using the +,- buttons. Press “OK” to
select the current timezone difference.
7) The time signal decoding can be manually stopped or started. Scroll to “Manual” and press
the “OK” key.
Rad i oCl oc k
Rad i oCl oc k
Rad i oC l oc k
No t Us e
DCF 7 7
Rad i oC l oc k
Rad i oC l oc k
Inpu t
TimeDi f fer
Rad i oC l o c k
Input
I01
Rad i oC l oc k
Rad i oC l oc k
Inpu t
TimeDi f fer
Rad i oC l oc k
0.0
TimeDi f fer
hrs
Rad i oC l oc k
Inpu t
TimeDi f fer
Manua l
