Mitsubishi alpha 2 User Manual

α 2 Simple Application Controllers
Specifications 2
ENG-8
2. Specifications
Note;
• Refer to chapter 9 about specification of the AL2-ASI-BD.
• Refer to chapter 11 about specification of the AL2-2DA.
• Refer to chapter 12 about specification of the AL2-2PT-ADP.
• Refer to chapter 13 about specification of the AL2-2TC-ADP.
2.1 Power Supply Specification
Table 2.1: Power Supply Specifications
Description Code Specification
Power Supply
AL2-***-A 100 - 240V AC~, +10% -15%, 50/60 Hz
AL2-***-D 24V DC, +20% -15%
Maximum Momentary Power
Failure
AL2-***-A 10ms
AL2-***-D 5ms
In-rush Current
AL2-***-A,
240V AC~ (120V AC~)
≤ 6.5 A (3.5 A) < 5ms
AL2-***-D, 24V DC ≤ 7.0 A
Maximum Power
Consumption
AL2-10MR-A, 264V AC~ 4.9 W
AL2-10MR-D, 28.8V DC 4.0 W
AL2-14MR-A, 264V AC~ 5.5 W
AL2-14MR-D, 28.8V DC 7.5 W
AL2-24MR-A, 264V AC~ 7.0 W
AL2-24MR-D, 28.8V DC 9.0 W
Typical Power Consumption
(without Special Connection
Modules)
AL2-10MR-A, 240V AC~ I/O all On - 3.5 W; I/O all Off - 1.85 W
AL2-10MR-A, 120V AC~ I/O all On - 3.0 W; I/O all Off - 1.55 W
AL2-10MR-D, 24V DC I/O all On - 2.5 W; I/O all Off - 0.75 W
AL2-14MR-A, 240V AC~ I/O all On - 4.5 W; I/O all Off - 2.0 W
AL2-14MR-A, 120V AC~ I/O all On - 3.5 W; I/O all Off - 1.5 W
AL2-14MR-D, 24V DC I/O all On - 4.0 W; I/O all Off - 1.0 W
AL2-24MR-A, 240V AC~ I/O all On - 5.5 W; I/O all Off - 2.5 W
AL2-24MR-A, 120V AC~ I/O all On - 4.5 W; I/O all Off - 2.0 W
AL2-24MR-D, 24V DC I/O all On - 5.0 W; I/O all Off - 1.0 W
