C-6
2 Specifications
2.1 Generic Specifications
FX
3U
/FX
3UC
Series PLC User's Manual - Analog Control Edition
FX3U-4AD-ADP (4-channel analog Input)
2. Specifications
This chapter describes the general, power supply, and performance specifications for 4AD-ADP.
2.1 Generic Specifications
*1. If 4AD-ADP is connected to the FX3UC Series PLC, direct installation is not possible.
*2.
→ For a detailed description of the grounding, refer to Section 3.5.
*3. If the pressure is higher than the atmospheric pressure, do not use 4AD-ADP.
4AD-ADP may malfunction.
Item Specifications
Ambient
temperature
0 to 55°C (32 to 131°F) when operating and -25 to 75°C (-4 to 158°F) when stored
Relative
humidity
5 to 95%RH (no condensation) when operating
Vibration
resistance
Compliant with EN 68-2-6
Frequency
(Hz)
Acceleration
(m/s
2
)
Half amplitude
(mm)
10 times of testing in
each direction (X-, Y-,
and Z-axis directions)
(Total: 80 min, each)
DIN Rail Mounting
10 - 57 - 0.035
57 - 150 4.9 -
Direct Mounting
*1
10 to 57 − 0.075
57 to 150 9.8 −
Shock
resistance
Compliant with EN 68-2-27
(147 m/s
2
Acceleration, Action time: 11ms, 3 times by half-sine pulse in each direction X, Y, and Z)
Noise
resistance
Using noise simulator of:
Noise voltage: 1,000Vp-p / Noise width: 1µs / Rise: 1ns / Cycle: 30 to 100Hz
Dielectric
withstand
voltage
500 V AC, for 1 min
(Between batch of all terminals and ground terminal)
Comply with JEM-1201
Insulation
resistance
5MΩ or more using 500V DC
insulation resistance meter
Grounding
Class D grounding (grounding resistance: 100 Ω or less)
<Common grounding with a heavy electrical system is not allowed.>
*2
Working
atmosphere
Free from corrosive or flammable gas and excessive conductive dusts
Working
altitude
Compliant with IEC61131-2 (<2000m)
*3
PLC
Another
equipment
PLC
Another
equipment
PLC
Another
equipment
Shared grounding
Good condition
Common grounding
Not allowed
Independent grounding
Best condition
