Common Items
1. Introduction
This manual describes the analog products of the FX3U/FX3UC Series PLC.
This chapter describes the analog control types and applications.
1.1 Outline and Features of Analog Control
For the FX Series, there are 3 types of analog control: Voltage/current input, voltage/current output, and
temperature sensor input.
Select products optimum for the purpose of use.
In addition to the above applications, the FX
3U/FX3UC Series PLC can be used for various purposes.
Thermocouple,
platinum resistance
thermometer
sensor
→ Refer to Subsection
1.1.3.
• FX 3 U -4AD-TC-ADP
• FX 3 U -4AD-PT-ADP
 Temperature sensor
input control type
FX 3UC Series PLC
Flowmeter,
pressure sensor, etc.
• FX 3U -4AD-ADP
• FX 3 UC -4AD
 Voltage/current input
control type
→ Refer to Subsection
1.1.1.
• FX 3 U -4DA-ADP
 Voltage/current
output control type
Inverter, etc.
→ Refer to Subsection
1.1.2.
FX 3U Series PLC
