4 Comparison of Performance Specifications
4.3 Analog Input/Output Mixture
FX
3U
/FX
3UC
Series PLC User's Manual - Analog Control Edition
Common Items
4.3 Analog Input/Output Mixture
2. Analog output
3. Other
Specifications
FX2N-5A
Voltage output Current output
Number of output points 1ch
Analog input/output range
-10V to +10V DC
(External load: 5k to 1MΩ)
0mA to 20mA DC
4mA to 20mA DC
(External load: 500Ω or less)
Absolute maximum input - -
Offset -1V to +9V 0mA to 17mA
Gain
10V or less, and
Gain - Offset ≥ 1V
30 mA or less, and
Gain - Offset ≥ 3mA
Digital input/output With sign, 12 bits, binary 10 bits, binary
Resolution 5mV(10V×1/4000) 20µA(20mA×1/1000)
Overall accuracy
Ambient temperature:
25±5°C
±0.5% (±100mV) for full scale of 20V
±0.5% (±200µA) for full scale of 40mA
Same for input of 4mA to 20mA
Ambient temperature:
0±55°C
±1.0% (±200mV) for full scale of 20V
±1.0% (±400µA) for full scale of 40mA
Same for input of 4mA to 20mA
Time required for conversion 2ms
I/O characteristics
Specifications FX2N-5A
Insulation method
• The photocoupler is used to insulate the analog input and output area from the
PLC.
• The DC/DC converter is used to insulate the power supply from the analog input
and output.
• Channels are not insulated from each other.
Number of I/O occupied
points
8 points (Count either the input or output points of the PLC.)
z
When the output mode is set to "0":
0
+32000
+10V
-10V
-32000
Approx.
+32767
Approx.
-32768
z
When the output mode is "4":
(The dotted line is for mode 2.)
0
32000
20mA
Digital input
4mA
Analog output
Approx. 32767
To Next Page
