5. PARAMETERS
5 - 11
5.1.7 Linear servo motor/DD motor setting parameters ([Pr. PL_ _ ])
Operation
mode
Control
mode
No. Symbol Name
Initial
value
Unit
Standard
Full.
Lin.
D.D.
P S
T
PL01 *LIT1 Linear servo motor/DD motor function selection 1 0301h
PL02 *LIM Linear encoder resolution - Numerator 1000 [µm]
PL03 *LID Linear encoder resolution - Denominator 1000 [µm]
PL04 *LIT2 Linear servo motor/DD motor function selection 2 0003h
PL05 LB1 Position deviation error detection level 0 [mm]/
[0.01rev]
PL06 LB2 Speed deviation error detection level 0 [r/min]/
[mm/s]
PL07 LB3 Torque/thrust deviation error detection level 100 [%]
PL08 *LIT3 Linear servo motor/DD motor function selection 3 0010h
PL09 LPWM Magnetic pole detection voltage level 30 [%]
PL10 For manufacturer setting 5
PL11 100
PL12 500
PL13 0000h
PL14 0000h
PL15 20
PL16 0
PL17 LTSTS Magnetic pole detection - Minute position detection method -
Function selection
0000h
PL18 IDLV Magnetic pole detection - Minute position detection method -
Identification signal amplitude
0 [%]
PL19 For manufacturer setting 0
PL20 0
PL21 0
PL22 0
PL23 0000h
PL24 0
PL25 0000h
PL26 0000h
PL27 0000h
PL28 0000h
PL29 0000h
PL30 0000h
PL31 0000h
PL32 0000h
PL33 0000h
PL34 0000h
PL35 0000h
PL36 0000h
PL37 0000h
PL38 0000h
PL39 0000h
PL40 0000h
PL41 0000h
PL42 0000h
PL43 0000h
PL44 0000h
PL45 0000h
PL46 0000h
PL47 0000h
PL48 0000h
