11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 66
11.12 Power factor improving AC reactors
The following shows the advantages of using power factor improving AC reactor.
It improves the power factor by increasing the form factor of the servo amplifier's input current.
It decreases the power supply capacity.
The input power factor is improved to be about 80%.
When using power factor improving reactors for two servo amplifiers or more, be sure to connect a power
factor improving reactor to each servo amplifier. If using only one power factor improving reactor, enough
improvement effect of phase factor cannot be obtained unless all servo amplifiers are operated.
(1) 200 V class
4-d mounting hole
(Varnish is removed from front right mounting
hole (face and back side).) (Note 1)
Terminal layout
RX ZSYT
W or less (Note 2)
W1
D1
D2
H
D or less
Fig. 11.7
Y
Z
S
T
Y
Z
S
T
MCMCCB
MCMCCB
FR-HAL
Servo amplifie
r
3-phase 200 V class
XR
L1
L2
L3
3-phase
200 V AC to
240 V AC
FR-HAL
Servo amplifier
1-phase 200 V class
XR
L1
L2
(Note)
1-phase
200 V AC to
240 V AC
L3
Note 1.
2.
Use this hole for grounding.
W ± 2 is applicable for FR-HAL-0.4K to FR-HAL-1.5K.
Note. For 1-phase 200 V AC to 240 V AC, connect the power
supply to L1 and L3. Leave L2 open.
4-d mounting hole
(Varnish is removed from front right mounting
hole (face and back side).) (Note)
Terminal layout
RX ZSYT
W ± 2
H
D1
D or less
W1
D2
Fig. 11.8
X
D or less
D1 ± 2
D2
W1
W or less
R
T
S
Y
Z
H ± 5
4-d mounting hole (Note)
Fig. 11.9
Note. Use this hole for grounding. Note. Use this for grounding.
