10. CHARACTERISTICS
10 - 4
10.2 Power supply capacity and generated loss
(1) Amount of heat generated by the servo amplifier
Table 10.1 indicates servo amplifiers' power supply capacities and losses generated under rated load.
For thermal design of an enclosed type cabinet, use the values in the table in consideration for the worst
operating conditions. The actual amount of generated heat will be intermediate between values at rated
torque and servo-off according to the duty used during operation. When the servo motor is run at less
than the rated speed, the power supply capacity will be smaller than the value in the table, but the servo
amplifier's generated heat will not change.
Table 10.1 Power supply capacity and generated loss per servo motor at rated output
(Note 2) Servo amplifier-generated heat [W]
Servo amplifier Servo motor
(Note 1)
Power supply
capacity
[kVA]
At rated output
At rated output
[Generated heat
in the cabinet
when cooled
outside the
cabinet] (Note 3)
With servo-off
Area required for
heat dissipation
[m
2
]
HG-MR053 0.3 25 15 0.5
HG-MR13 0.3 25 15 0.5
HG-KR053 0.3 25 15 0.5
MR-J4-10A(-RJ)
HG-KR13 0.3 25 15 0.5
HG-MR23 0.5 25 15 0.5
MR-J4-20A(-RJ)
HG-KR23 0.5 25 15 0.5
HG-MR43 0.9 35 15 0.7
MR-J4-40A(-RJ)
HG-KR43 0.9 35 15 0.7
HG-SR52 1.0 40 15 0.8
HG-SR51 1.0 40 15 0.8
MR-J4-60A(-RJ)
HG-JR53 1.0 40 15 0.8
HG-MR73 1.3 50 15 1.0
HG-KR73 1.3 50 15 1.0
HG-UR72 1.3 50 15 1.0
MR-J4-70A(-RJ)
HG-JR73 1.3 50 15 1.0
HG-SR102 1.7 50 15 1.0
HG-SR81 1.5 50 15 1.0
HG-JR73 1.3 50 15 1.0
MR-J4-100A(-RJ)
HG-JR103 1.7 50 15 1.0
HG-SR152 2.5 90 20 1.8
HG-SR202 3.5 90 20 1.8
HG-SR121 2.1 90 20 1.8
HG-SR201 3.5 90 20 1.8
HG-RR103 1.7 50 15 1.0
HG-RR153 2.5 90 20 1.8
HG-UR152 2.5 90 20 1.8
HG-JR153 2.5 90 20 1.8
MR-J4-200A(-RJ)
HG-JR203 3.5 90 20 1.8
HG-SR352 5.5 130 20 2.6
HG-SR301 4.8 120 20 2.4
HG-RR203 3.5 90 20 1.8
HG-UR202 3.5 90 20 1.8
MR-J4-350A(-RJ)
HG-JR353 5.5 160 20 2.7
HG-SR502 7.5 195 25 3.9
HG-SR421 6.3 160 25 3.2
HG-RR353 5.5 135 25 2.7
HG-RR503 7.5 195 25 3.9
HG-UR352 5.5 195 25 3.9
HG-UR502 7.5 195 25 3.9
MR-J4-500A(-RJ)
HG-JR503 7.5 195 25 3.9
HG-SR702 10 300 25 6.0
MR-J4-700A(-RJ)
HG-JR703 10 300
25 6.0
