11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 50
11.6 Junction terminal block MR-TB50
(1) Usage
Always use the junction terminal block (MR-TB50) with the option cable (MR-J2M-CN1TBL_M) as a set.
Servo amplifier
CN1
Junction terminal block
MR-TB50
Junction terminal
block cable
(MR-J2M-CN1TBL_M)
Cable clamp
Ground the option cable on the junction terminal block side with the cable clamp fitting (AERSBAN-
ESET). For the use of the cable clamp fitting, refer to section 11.14, (2) (c).
(2) Terminal labels
Use the following junction terminal block labels. This label is supplied with the junction terminal block
MR-TB50.
SONP15R LG LAR LBR LZR PG PC RES
DICOM
ZSP TLC TLA OP NP CR LSP LOP
DOCOM
RD
LA LB LZ PP OPC TL INP INP LG LG NG EMG LSN ALM SD
DICOM
LG
DOCOM
Position control mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
SONP15R LG LAR LBR LZR ST1 RES
DICOM
ZSP TLC TLA OP SP1 LSP LOP
DOCOM
RD
LAVC LB LZ ST2 SA SASP2 LG LG EMG LSN ALM SD
DICOM
LG
DOCOM
Speed control mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
SONP15R LG LAR LBR LZR SR2 RES
DICOM
ZSP VLC TC OP SP1 LOP
DOCOM
RD
LAVLA LB LZ RS1SP2 LG LG EMG ALM SD
DICOM
LG
DOCOM
Torque control mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
(3) Dimensions
[Unit: mm]
235
50
25
Approx.
25
9
2
1
50
49
MITSUBISHI
MR-TB50
4.5
Terminal screw: M3.5
Applicable wire: 2 mm
2
Crimp terminal width: 7.2 mm or less.
244
2.5
46.5
1 3 5 7 9 1113 15 171921 232527 29 3133
2 4 6 8 101214 16182022 2426 2830 32
35 3739 414345 47 49
34 36 3840 42444648 50
2-
