11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 2
11.1.1 Combinations of cable/connector sets
For MR-J4-_A_ servo amplifier
Refer to "Servo Motor Instruction Manual (Vol. 3)" for options for servo
motor power supply, electromagnetic brake, and encoder.
CNP1
CNP2
CNP3
5)
1)
7)
CN9
CN10
MR-J3-D05
2)
3)
4)
CN5
CN6
CN3
CN8
CN1
CN2
CN4
6)
Linear servo motor
Linear encoder
Power supply
connector
Direct drive motor
Encoder
connector
To CN2
To CN2
(The connection method changes
depending on incremental system
and absolute position detection system.)
Refer to "Liner Encoder Instruction Manual" about options for
liner encoder.
Refer to "Direct Drive Motor Instruction Manual" about options
for direct drive motor power and encoder.
Battery
(Packed with the
servo amplifier)
(Note 1)
Personal computer
To 24 V DC power supply
for electromagnetic brake
Servo motor
Encoder
connector
Safety logic unit
Servo amplifier
Operation
panel
Controller
Power supply
connector
Brake
connector
(Note 2)
Note 1. Connectors for 3.5 kW or less. For 5 kW or more, it is a terminal block.
2. When not using the STO function, attach a short-circuit connector (8)) supplied with a servo amplifier.
To Next Page
