16. USING A DIRECT DRIVE MOTOR
16 - 17
16.5.2 Power supply capacity and generated loss
Table 16.1 indicates servo amplifiers' power supply capacities and losses generated under rated load. For
thermal design of an enclosed type cabinet, use the values in the table in consideration for the worst
operating conditions. The actual amount of generated heat will be intermediate between values at rated
torque and servo-off according to the duty used during operation. When the servo motor is run at less than
the rated speed, the power supply capacity will be smaller than the value in the table, but the servo
amplifier's generated heat will not change.
Table 16.1 Power supply capacity and generated loss per direct drive motor at rated output
Servo amplifier-generated heat [W]
Servo motor
Power supply
capacity [kVA]
At rated output With servo-off
Area required for heat
dissipation [m
2
]
TM-RFM002C20 0.25 25 15 0.5
TM-RFM004C20 0.38 35 15 0.7
TM-RFM006C20 0.53 40 15 0.8
TM-RFM006E20 0.46 40 15 0.8
TM-RFM012E20 0.81 50 15 1.0
TM-RFM018E20 1.3 50 15 1.0
TM-RFM012G20 0.71 50 15 1.0
TM-RFM048G20 2.7 90 20 1.8
TM-RFM072G20 3.8 110 20 2.2
TM-RFM040J10 1.2 50 15 1.0
TM-RFM120J10 3.4 90 20 1.8
TM-RFM240J10 6.6 160 25 3.2
