2. Turn the socket (A) anticlockwise to re-
move it, and then pull the bulb out of the
socket.
3. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lamp unit, first insert the
notch (B) into the hole on the body, and then
push on the lamp unit to fit it into place.
Rear combination lamps
E01004202767
1. Open the tailgate.
2. Remove the screws (A), and then move
the lamp unit towards the rear of the ve-
hicle to unfix the notch (B) and pins (C)
of the lamp unit.
3. Turn the socket anticlockwise and re-
move it, and then pull the bulb out of the
socket.
Replacement of lamp bulbs
10-29
OGFE16E1
Maintenance
10
