3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3.5 RUN, STOP, PAUSE Operation Processing
3 - 67
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(4) CPU module operation processing by switch operation
* 1: Since the Basic model QCPU cannot execute multiple programs, it cannot use subroutine
programs in the other programs.
POINT
The CPU module performs the following in any of RUN, STOP, and PAUSE
status:
• I/O module refresh processing
• Network module refresh processing
• Automatic refresh processing of intelligent function module
• Self-diagnostic processing
• Communication processing with external device such as GX Developer
• Processing of instructions dedicated to intelligent function modules
(completion processing only)
• Operation processing of Multiple CPU high speed transmission function
(Universal model QCPU only)
Even if the CPU module is in STOP or PAUSE status, the following operations can
be executed.
• I/O monitor or test operation using GX Developer
• Read/write from/to the external device using the MC protocol
• Communication with other stations using CC-Link IE controller network
and MELSECNET/H
• Communication with CC-Link remote stations
Table3.6 Operation processing by switch operation
RUN/STOP status
CPU module operation processing
Sequence
program
operation
processing
External output
Device memory
M,L,S,T,C,D Y
RUN STOP
Executes up to
the END
instruction and
stops.
Saves the output (Y)
status immediately before
switching to the STOP
status, and turns all points
OFF.
Saves the device memory status
immediately before switching to
the STOP status.
Saves the output (Y)
status immediately
before switching to the
STOP status, and turns
all points OFF.
STOP RUN Starts at step 0.
Determined by the
"STOP RUN-time output
mode" in the PLC
parameter dialog box.
Saves the device memory status
immediately before switching to
the STOP status.
However, when the initial device
values have been set, the values
are used.
Clears the local devices
*1
.
Determined by the
"STOP RUN-time
output mode" in the
PLC parameter dialog
box.
( Section 6.4)
