Appendix 3 List of Parameter No.
APPENDICES
Appendix 3 List of Parameter No.
The parameter No. is stored into the special register (SD16 to 26), when an error occurs in
the parameter settings.
The table for the parameter No. and parameter setting area is shown in this section.
Refer to Section 9.3 for the explanation of mn, **, M, N in the "Parameter No." column.
(Continued on next page)
TableApp.39List of parameter No.
Item Parameter No. Referance
Label 0000H Section 9.1.1(1),
Section 9.1.2(1)
Comment 0001H
I/O assignment
Type
0400
H
Section 4.7
Section 9.1.1(8)
Section 9.1.2(10)
Model name
points
Start XY (Start I/O No.)
Basic setting
Base model name
0401
H
Section 4.4
Section 9.1.1(8)
Section 9.1.2(10)
Power model name
Extension cable
Slots
Detail setting
Error time output mode 0403H
Section 6.8
Section 9.1.1(8)
Section 9.1.2(10)
I/O response time 0405H
Section 6.7
Section 9.1.1(8)
Section 9.1.2(10)
Control PLC 0406H
Section 9.1.1(8)
Section 9.1.2(10)
QCPU User’s Manual
(Muitiple CPU System)
Switch setting 0407H
Section 6.10
Section 9.1.1(8)
Section 9.1.2(10)
Group No.
05mn
H Section 9.3(2)
0AmnH Section 9.3(2)
Redundant Parameter 0D00H
Section 9.2
QnPRCPU User’s Manual
(Redundant System)
