5 - 48
5.2 High Performance Model QCPU, Process CPU, Redundant CPU, Universal Model QCPU
5.2.9 Execution of standard ROM/memory card programs (boot run)
5
MEMORIES AND FILES USED IN CPU MODULE
5.2.9 Execution of standard ROM/memory card programs (boot run)
This section explains how to operate the programs stored in the standard ROM
Note5.11
or
memory card.
(1) How to execute the standard ROM/memory card programs
The CPU module operates the programs stored in the program memory.
It does not operate the programs stored in the standard ROM or memory card.
To do this, make setting to boot (read) the programs in the standard ROM or memory
card to the program memory at power-on or reset.
( (3), (4) below)
The programs having the file names specified in the boot file setting are booted from
the standard ROM or memory card to the program memory at power-on or reset.
Figure 5.36 Boot run
Universal
UD
Note5.11
Program
memory
Boot
Memory card
Boot
Standard
ROM
In the Universal model QCPU, a program cannot be executed from the standard ROM.
Note5.11
Universal
UD
