6
FUNCTIONS
6.1 Function List
6 - 1
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
CHAPTER6 FUNCTIONS
This chapter explains the functions of the CPU module.
6.1 Function List
Table6.2 lists the functions of the CPU module.
The numbers in the "CPU module" column correspond to the CPU modules as indicated in
Table6.1.
: Supported, : Not supported
(Continued on next page)
Table6.1 Number in the "CPU module" column and corresponding CPU module
No. CPU module
1) Basic model QCPU
2) High Performance model QCPU
3) Process CPU
4) Redundant CPU
5) Universal model QCPU
Table6.2 CPU module function list
Item Description
CPU module
Reference
1) 2) 3) 4) 5)
Constant scan
Executes the program in a set time interval
regardless of the program scan time.
Section 6.2
Latch function Retains the device data even at power OFF or reset. Section 6.3
Output status selection when the
status changed from STOP to RUN
Selects the output (Y) status (outputting the same
status prior to STOP or clearing the status) when the
CPU module status is switched from STOP to RUN.
Section 6.4
Clock function
Reads the internal clock data of the CPU module to
use it for time management.
Section 6.5
Remote RUN/STOP Stops or executes operations in the CPU module.
Section
6.6.1
Remote PAUSE
Stops operations in the CPU module while retaining
the status of output (Y).
Section
6.6.2
Remote RESET
Resets the CPU module when the CPU module is in
a STOP status.
Section
6.6.3
Remote latch clear
Clears the latch data of the CPU module when the
CPU module is in a STOP status.
Section
6.6.4
Input response time selection
Selects the input response time for the Q series
compatible input modules, I/O combined modules,
high-speed input modules, and interrupt modules.
Section 6.7
To Next Page
