Mitsubishi Q02HCPU User Manual

7
COMMUNICATION USING BUILT-IN ETHERNET
PORTS OF CPU MODULE
7 - 1
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
CHAPTER7 COMMUNICATION USING BUILT-IN
ETHERNET PORTS OF CPU MODULE
The Built-in Ethernet port QCPU can communicate data by connecting built-in Ethernet
ports of the CPU module with personal computers and/or display devices using an
Ethernet cable (100BASE-TX, 10BASE-T).Note1
For the comparison with the conventional MELSEC-Q series Ethernet module (QJ71E71-
100), refer to Appendix 6.
The following table lists the functions using built-in Ethernet ports of the CPU module.
Figure 7.1 Connection example using built-in Ethernet ports of CPU module
Note1
Table7.1 List of functions
Function Reference
GX Developer/GOT connection Section 7.2
GX Developer direct connection (simple connection) Section 7.3
MC protocol communication Section 7.4
Time setting function (SNTP client) Section 7.5
File transfer function (FTP server) Section 7.6
Remote password Section 7.7
Basic
Note7.1
Note7.1
Note7.1
High
Performance
Process
Note7.1
Redundant
Universal
UD
Note7.1
GX Developer
Hub
Ethernet
MC protocol FTP GOT
Only the Built-in Ethernet port QCPU has the built-in Ethernet ports.
Basic
Redundant
Note7.1
Process
High
Performance
Note7.1Note7.1
Note7.1
Universal
UD
Note7.1
