MEMORIES AND FILES USED IN CPU MODULE
5.2 High Performance Model QCPU, Process CPU, Redundant CPU, Universal Model QCPU
5.2.9 Execution of standard ROM/memory card programs (boot run)
5 - 49
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(2) Types of files can be booted and a transfer source and transfer
destination
The file can be booted, its transfer source or transfer destination depends on the CPU
module.
The following table shows the executable combination for boot run.
(a) High performance model QCPU, Process CPU, and Redundant CPU
: Boot available, : Boot not available
(b) Universal model QCPU
: Boot available, : Boot not available
Table5.9 Available files for boot run
File name
Transfer source
Transfer destination
Memory card Standard ROM
Parameter
Program memory
Sequence program
Device comment
Device initial value
Table5.10 Available files for boot run
File name Transfer source
Transfer destination
Program memory Standard ROM
Parameter
Memory card
Sequence program
Device comment
Device initial value
Label program
