5.2 High Performance Model QCPU, Process CPU, Redundant CPU, Universal Model QCPU
5.2.9 Execution of standard ROM/memory card programs (boot run)
5
MEMORIES AND FILES USED IN CPU MODULE
(3) Procedure before boot run
The following describes the procedure before boot run.
(a) Program creation by GX Developer
Create programs for boot run.
(b) Boot file by GX Developer
To execute the programs in the standard ROM or memory card, set the names of
files to be booted (read) to the program memory in the boot file of the PLC
parameter dialog box.
(c) Hardware setting for boot run
Set the parameter-valid drive DIP switches to indicate the memory that will store
the parameters.
Note5.12
Note10
When executing boot run, set the parameter storage location to the standard
ROM or memory card. ( (5)(a)in this section)
Figure 5.37 Boot file
Note10
Figure 5.38 When parameter-valid drive DIP switches are set to SRAM card
Universal
UD
Note5.12
The Universal model QCPU does not require hardware settings for boot run.
Note5.12
Universal
UD
1
2
3
4
5
ON SW
