5
MEMORIES AND FILES USED IN CPU MODULE
5.2 High Performance Model QCPU, Process CPU, Redundant CPU, Universal Model QCPU
5.2.2 Program memory
5 - 23
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
(4) Write to program memory
To write data to the program memory, choose [Online] [Write to PLC] on GX
Developer.
Select "Program memory/Device memory" as the target memory on the Write to PLC
screen and write data to the PLC.
POINT
The file size has the minimum unit. ( Section 5.4.4)
The occupied memory capacity may be greater than the actual file size.
Note that as the number of files rises, the difference between the occupied
memory capacity and actual file size increases.
Figure 5.16 Write to PLC screen
To Next Page
