1 - 17
1.1 Features
1.1.3 Features of Process CPU
1
OVERVIEW
(4) Module can be replaced online (Online module change)
When a module becomes faulty, it can be replaced without the system being stopped.
Modules available for this are the Q series I/O modules, and the A/D converter
modules, D/A converter modules, temperature input modules, temperature control
modules and pulse input modules of function version C.
Refer to the following manuals for details of the online module change.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
Manuals of the modules compatible with the online module change
(5) Configuration of MELSECNET/H multiplexed remote I/O system
A MELSECNET/H multiplexed remote I/O system can be configured,mounting a
remote master station in the MELSECNET/H network system.
(6) Supporting software package dedicated to process control
Using the process control software package (PX Developer), PID control programs
can be created easily with function blocks.
The combination of the Process CPU and the process control software package (PX
Developer) offers an excellent engineering environment.
POINT
1. When using the Q12PHCPU and Q25PHCPU, use GX Developer Version
7.10L or later.
When using the Q02PHCPU and Q06PHCPU, use GX Developer Version
8.68W or later.
2. Use PX Developer together with GX Developer Version 7.20W or later.
Refer to the PX Developer manual for details.
When using the Q12PHCPU and Q25PHCPU, use PX Developer Version
1.00A or later.
When using the Q02PHCPU and Q06PHCPU, use PX Developer Version
1.18U or later.
3. New functions of a CPU module may be added depending on the upgrade of
the serial number of the CPU module or the function version of GX Developer.
For the list of functions have been added with the upgrade of the Process
CPU, refer to Appendix 4.3.
