2.2 High performance model QCPU
2 - 7
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
Remark
Refer to the following manual for the general specifications.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
Table2.2 Performance Specifications
Item
High performance model QCPU
Q02CPU Q02HCPU Q06HCPU Q12HCPU Q25HCPU
No. of device points
Special relay [SM] 2048 points (SM0 to 2047) (The number of device points is fixed)
Special register [SD] 2048 points (SM0 to 2047) (The number of device points is fixed)
Function input [FX] 16 points (FX0 to F) (The number of device points is fixed)
Function output [FY] 16 points (FY0 to F) (The number of device points is fixed)
Function register [FD] 5 points (FD0 to 4) (The number of device points is fixed)
No. of device tracking words ----
Link direct device
Device for accessing the link device directly
Dedicated to CC-Link IE controller network and MELSECNET/H.
Specified form: J \X , J \Y , J \W ,
J\B, J\SW, J\SB
Intelligent function module device
Device for accessing the buffer memory of the intelligent function module directly.
Specified form: U \G
Latch range
L0 to 8191 (default)
(Latch range can be set up for B, F, V, T, ST, C, D, and W.) (Setting by parameters)
RUN/PAUSE contact One contact can be set up in X0 to 1FFF for each of RUN and PAUSE. (Setting by parameters)
Timer function
Year, month, date, hour, minute, second, and day-of-week
(leap year automatically identified)
Accuracy: -3.18 to +5.25s(TYP.+2.12s)/d at 0
Accuracy: -3.93 to +5.25s(TYP.+1.90s)/d at 25
Accuracy: -14.69 to +3.53s(TYP.-3.67s)/d at 55
Allowable instantaneous power failure
period
Varies depending on the power supply module.
5VDC internal current consumption 0.60A 0.64A
External dimensions
H 98mm (3.86inch)
W 27.4mm (1.08inch)
D 89.3mm (3.52inch)
Weight 0.20kg
