4 - 6 4 - 6
MELSEC-Q
4 MODBUS
R
STANDARD FUNCTIONS
4.3.1 Read coils (FC: 01)
Reads the statuses (ON/OFF) of one or more coils.
Number of accessible devices with one message
1 to 2000 points
(1) Request message format (Master Slave)
Head coil number
Data
Read points
(H) (L) (H) (L)
Function code
Function code
(0000
H
to FFFF
H
)(01
H
) (0001
H
to 07D0
H
)
(2) Response message format (Slave Master)
(When completed normally)
DataFunction code
Function code
Device data
1
Device data
n
(Number of read bytes n)
(Device data 1 to n)
Device data 1
b0b1b2b3b4b5b6b7
Device data n
0 : OFF
1 : ON
The read coil statuses are stored in order from low-order to high-order bits.
When the number of read points is not a multiple of 8, the excess bits turn to 0.
Bit device storage
order
(01
H
)
Number of
read bytes
n
(When completed with an error)
Data
Function code
Function code
(81
H
)
Exception
code*
: When completed with an error, the exception code and error code are stored
into the buffer memory.
Refer to Section 11.3 for the storage location, confirmation method and more
details.
To Next Page
