6 - 4 6 - 4
MELSEC-Q
6 PRE-OPERATIONAL PROCEDURES AND SETTING
6.3 Part Names
This section indicates the names of the QJ71MT91 parts.
QJ71MT91
10BASE-T/100BASE-TX
RUN
INIT.
OPEN
SD RD
COM.ERR.
ERR.
QJ71MT91
100M
1)
2)
Name Description
1) Indicator LEDs Refer to the following section, (1) Indications of indicator LEDs.
2)
10BASE/T/100BASE-TX
connector (RJ45)
1
Connector for connection of the QJ71MT91 to 10BASE-
T/100BASE-TX.
(The QJ71MT91 detects whether 10BASE-T or 100BASE-TX is
used according to the hub.)
1: The LED on the connector is not lit.
