Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
ENGLISH
GENERAL ELECTRICAL SYSTEM
112 / 195
ELECTRICAL SYSTEM
28 GENERAL
28.1 Specifications (standard)
1
1. All specifications are subject to change without any prior
notice.
Engine model S3L/S3L2 S4L/S4L2
Starter
Model M1T68281 M8T70471
Type DC solenoid shifted (with reduction gear)
Nominal output, V–kW 12 - 1.7 12 - 2.0
Alternator
Model A7T02071C
Regulator, type IC
Nominal output, V–A 12 – 50
Glow plug
Model 008816-4C
Type Sheathed
Rated voltage, V 10.5
Current draw, A 9.7 ± 1.0 (30 seconds at rated voltage)
Glow plug
relay
Model G71SP
Rated voltage, V DC 12
Continuous rating 1 minute
Resistance in coil,
Ω
13
Control timer
unit
Model YM-1C
Input voltage range, V DC 9 to 15
Load Solenoid (resistance in coil: 1.7
Ω minimum)
ETS type stop
solenoid
Model YMS-1
Type Solenoid
Resistance in coil, Ω 1.8 ± 10% at 20°C (68°F)
Stroke, mm (in.) 13 ± 0.5 (0.53 ± 0.02)
Operating voltage, V DC 10 to 15
Glow timer
Model QGS
Rated voltage, V DC 12
Operating voltage, V 7 to 15
Operating temperature
range °C (°F)
-30 to +70 (-22 to 158)
Storage temperature
range °C (°F)
-40 to +80 (-40 to 176)
Pre-glow time, second 6.2 ± 0.7
