Service Manual Mitsubishi SL-Series diesel engines
V
ersion 08/2004
INSPECTION
ENGLISH
COOLING SYSTEM
COOLING SYSTEM
35
INSPECTION
Figure 205
Inspection points
Check for cracks or
leaks.
Check for elongation,
aging or wear
.
Check for cracks or
distortion.
Use new gaskets.
T
est thermoswitch
and thermounit
using the
procedures that
follow
.
T
est thermost
at using
the procedure th
at
follows.
Check for aging or
damage
136
