Mitutoyo Measuring Projector User Manual

1. Overview
1.1.3 Angle counter and X, Y counter
(1) Angle counter (2) X, Y-axis counter
[2] [7] [8] [6]
[10]
[9] [3] [5] [4] [1]
(1) Angle counter
[1] Angle display unit
[2]
Zero-set key
[3]
ABS/INC mode indicator
[4]
Angle unit selector / offset switch
[5]
ABS/INC mode selector switch
(2) X, Y-axis counter
[6] mm/E indicator or inch/mm indicator
[7]
X-axis counter
[8]
Y-axis counter
[9]
X-axis zero-set switch
[10]
Y-axis zero-set switch
No.99MBA043A 1 - 3
