Mitutoyo Measuring Projector User Manual


Troubleshooting
4
4.1 Main Unit
Symptom Check point Remedy
1)
The fan motor
does not operate,
even if the power
switch is on.
1)Is the power cord securely
connected?
2)
Is the power supply voltage
consistent with the rated voltage?
3)
Is the fuse OK? (not blown)
1)
Connect the power cord
securely.
2)
Adjust the power supply
voltage to the rated voltage.
3)
Replace the fuse.
2)
The transmitted
illumination
halogen bulb dose
not light up
1)Is the pilot lamp on?
2)Is the cable for the transmitted
illuminator properly connected.
3)Is the illumination halogen bulb OK?
1) Refer to the symptom1.
2) Connect the cable properly.
3)Replace the halogen bulb.
3)
The vertical
reflected
illumination
halogen bulb dose
not light up.
1)Is the pilot lamp on?
2)Is the cable for the vertical reflected
illuminator properly connected.
3)Is the illumination halogen bulb OK?
1) Refer to the symptom1.
2) Connect the cable properly.
3)Replace the halogen bulb.
4)
The image is
unclear.
1)Check if the lens and workpiece are
stained.
2)Check if the light intensity of the
illumination is improper.
3)Check if the lens is loosened.
4)Check the environments for
vibration and electric noise.
1) Clean the lens and workpiece.
2)Adjust the light intensity.
3)Tighten the lens.
4)Optimize the environmental
conditions.
5)
Abnormal sound
and vibration are
generated.
1)Check if the legs on the main
unit/installation stand are loose.
2)Check if the main unit/installation
stand is not level.
1)Tighten the legs on the main
unit/installation stand correctly.
2)Perform leveling of the main
unit/installation stand.
6)
The measurement
data will not be
steady.
1)Check if the stage glass is fixed.
2)Check if the lens is loosened.
3)Check if the workpiece is fixed
properly.
4)Check if the lens and
glass are
contaminated.
5)Check if the environmental
conditions such as the temperature
and vibration are within the
tolerance range.
1)Fix the stage glass
2)Tighten the lens.
3) Fix the workpiece properly.
4) Clean the lens and
glass.
5)Optimize the environmental
conditions.
No.99MBA043A 4 - 1
