2.4.3 Projection with contour illumination

1. Turn on the contour illumination bulb.

(Use the brightness selector switch (HIGH and LOW) to select the light intensity.)

2. The workpiece profile is projected on the screen.

Projection screen

Workpiece profile

2 - 16 No.99MBA043A
