Mitutoyo Measuring Projector User Manual

5. Maintenance
5.5 List of Consumable
Order No. Part name Remark
512305
Halogen bulb
24V-150W (Life : 500 hours)
515530
Halogen bulb
24V-150W (Life : 50 hours)
384211
Tube fuse
BS SEMKO S506 5A (for 200V-system region)
12BAE152
51MS080H 8A (for 100V-system region)
Dimensions
φ 80mm
200673 Stage glass for
PJ-A3000
Effective area
φ 70mm
Dimensions 110 X 96mm (4.33 X 3.78”) 380405 Stage glass for
PJ-A3005R-50
Effective area 82
X 82mm (3.23 X 3.23”)
Dimensions 110 X 96mm (4.33 X 3.78”) 380405 Stage glass for
PJ-A3005D-50
Effective area 82
X 82mm (3.23 X 3.23”)
Dimensions 154 X 154mm (6.06 X 6.06”) 12BAE041 Stage glass for
PJ-A3010F-100
Effective area 142
X 142mm (5.59 X 5.59”)
Dimensions 196 X 96mm (7.72 X 3.78”) 381349 Stage glass for
PJ-A3005F-150
Effective area 184
X 82mm (7.24 X 3.23)
Dimensions 280 X 180mm (11.02 X 7.09”) 382762 Stage glass for
PJ-A3010F-200
Effective area 266
X 170mm (10.47 X 6.69)
No.99MBA043A 5 - 7
