Motorola APX 4000 User Manual

Removing and Attaching the Accessory
Connector Cover
The accessory connector is located on the antenna
side of the radio. It is used to connect accessories to
the radio.
Note: To prevent damage to the connector, shield it
with the connector cover when not in use.
1 To remove the accessory connector cover, rotate
the thumbscrew counterclockwise until it
disengages from the radio.
Note: If the thumbscrew is too tight, use an Allen
wrench at to loosen it first.
See the following picture for MFK radio.
A
B
C
See the following picture for two knobs
radio.
Preparing Your Radio for Use
24
English

Motorola APX 4000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 380-470 MHz, 450-520 MHz
Power Output	VHF: 1-5W; UHF: 1-4W
Digital Protocol	APCO P25
Dimensions	5.2 x 2.4 x 1.5 inches (without battery)
